HT instruments PVCHECK - Manual (Page 40)

PVCHECK
EN - 38
6.3.4.1. Anomalous situations when performing IVCK tests
1. In case the instrument detects a voltage higher than
1000V at terminals P-N, P-E and N-E, it does not carry
out the test, gives out a long sound and displays the
message “Vin > 1000”.
15/05/12 15:34:26
M o d u l e : S U N P W R 3 1 8
V d c : 0 . 0 V
I r r : 0 W / m 2
T c : A u t o ° C
V o c , I s c :
R i ( 1 0 0 0 V ) - - - M

R p e ( C a l ) - - - 
Vin > 1000
Selection I V C K
2. In case the instrument detects a voltage lower than 15V
at terminals P and N, it does not carry out the test, gives
out a long sound and displays the message “Low
voltage”.
15/05/12 15:34:26
M o d u l e : S U N P W R 3 1 8
V d c : 0 . 0 V
I r r : 0 W / m 2
T c : A u t o ° C
V o c , I s c :
R i ( 1 0 0 0 V ) - - - M

R p e ( C a l ) - - - 
Low voltage
Selection I V C K
3. In case the instrument detects a voltage higher than > 5V
at terminals E and C, it does not carry out the test, gives
out a long sound and displays the message “Voltage >
Lim”.
15/05/12 15:34:26
M o d u l e : S U N P W R 3 1 8
V d c : 0 . 0 V
I r r : 0 W / m 2
T c : A u t o ° C
V o c , I s c :
R i ( 1 0 0 0 V ) - - - M

R p e ( C a l ) - - - 
Voltage > Limit
Selection I V C K
4. In case the instrument detects an Isc current higher than
10A, it does not carry out the test, gives out a long sound
and displays the message “Isc current too high”.
15/05/12 15:34:26
M o d u l e : S U N P W R 3 1 8
V d c : 0 . 0 V
I r r : 0 W / m 2
T c : A u t o ° C
V o c , I s c :
R i ( 1 0 0 0 V ) - - - M

R p e ( C a l ) - - - 
Isc current too high
Selection I V C K
