Features

Simultaneous DMM and DSO
operation

Portrait and landscape modes

Large 800 x 480 TFT panel and
capacitive touch panel

7.4V/6100mAH battery for up to 4
hours operation

Support for differential probes

Handy APPs - EE calculator, chip
resistance calculator, attenuation
calculator

Shielded BNC terminals

DSO Features

X-Y mode

Go/No Go

36 automatic measurement functions

Trend plot

Edge, Alt, Video and Pulse trigger
functions

FFT, FFTrms, +, -, /, * math functions

Replay function

DMM Features

50,000 counts

DCV, DCA, ACV, ACA, R, Diode,
Continuity, Temperature

Fuse protection for the current ports

Interface

Mini-B USB device port
