G

ETTING STARTED

The Getting started chapter introduces the series lineup,
main features, appearance, and set up procedure.

Series Lineup

There are 6 models in the series, divided by DSO
bandwidth, DSO memory depth and DMM digit
resolution.

Model Name Bandwidth Memory

Depth

DMM
Resolution

Temp.
Meas.

GDS-207

70MHz

1M
points
per
channel

No

GDS-210

100MHz

GDS-220

200MHz

GDS-307

70MHz

5M
points
per
channel

Yes

GDS-310

100MHz

GDS-320

200MHz

Performance •

1 G Sa/s sampling rate max

70/100/200MHz bandwidth

Acquisition memory: 1Mpts (GDS-
200), 5Mpts (GDS-300)

Max 300Vrms(CAT II, DSO);
600V(CAT II) or 300V(CAT III) for
DMM

30,000 waveforms can be replayed
