AC Current*
Range

50mA, 500mA, 10A 3 ranges

Accuracy

50mA, 500mA, ±(1.5% + 15
digits) at 50Hz-1kHz; 10A ±(3%
+ 15 digits) at 50Hz - 1kHz

* Measure range: >10mA

Resistance*
Range

500Ω, 5kΩ, 50kΩ, 500kΩ, 5MΩ,
5 range

Accuracy

500Ω, 5kΩ, 50kΩ, 500kΩ ±(0.3%
+ 3 digits); 5MΩ ± (0.5% + 5
digits)

* Measure range: 50Ω to 5MΩ

Diode Test

Maximum forward voltage
1.5V, Open voltage 2.8V

Temperature (Thermocouple)*
Range

-50°C - + 1000°C

Resolution

0.1°C

Thermocouple

B, E, J, K, N, R, S, T

* Specifications do not include probe accuracy.
Temperature specifications only apply to the GDS-
307/310/320.

Continuity Beeper

< 15 Ω

Diode Test
Functions

Auto Range, Max, Min, Hold,
Trend plot
