1600A-N4X Instruction Manual Rev. 0.2 Page 24 of 38
40002 Channel 3 Reading
40003 Channel 4 Reading
40004 Channel 5 Reading
40005 Channel 6 Reading
40006 Channel 7 Reading
40007 Channel 8 Reading
40008 Channel 9 Reading
40009 Channel 10 Reading
40010 Channel 11 Reading
40011 Channel 12 Reading
40012 Channel 13 Reading
40013 Channel 14 Reading
40014 Channel 15 Reading
40015 Channel 16 Reading
40016 Fault Status Bits
High Byte
Bit 7
1 = Channel 16 Fault 0 = Channel 16 no Fault
Bit 6 1 = Channel 15 Fault 0 = Channel 15 no Fault
Bit 5 1 = Channel 14 Fault 0 = Channel 14 no Fault
Bit 4 1 = Channel 13 Fault 0 = Channel 13 no Fault
Bit 3 1 = Channel 12 Fault 0 = Channel 12 no Fault
Bit 2 1 = Channel 11 Fault 0 = Channel 11 no Fault
Bit 1 1 = Channel 10 Fault 0 = Channel 10 no Fault
Bit 0 1 = Channel 9 Fault 0 = Channel 9 no Fault
Low Byte
Bit 7
1 = Channel 8 Fault 0 = Channel 8 no Fault
Bit 6 1 = Channel 7 Fault 0 = Channel 7 no Fault
Bit 5 1 = Channel 6 Fault 0 = Channel 6 no Fault
Bit 4 1 = Channel 5 Fault 0 = Channel 5 no Fault
Bit 3 1 = Channel 4 Fault 0 = Channel 4 no Fault
Bit 2 1 = Channel 3 Fault 0 = Channel 3 no Fault
Bit 1 1 = Channel 2 Fault 0 = Channel 2 no Fault
Bit 0 1 = Channel 1 Fault 0 = Channel 1 no Fault
40017 Alarm 1 Status Bits
High Byte
Bit 7
1 = Channel 16 Alarm 1 0 = Channel 16 no Alarm 1
Bit 6 1 = Channel 15 Alarm 1 0 = Channel 15 no Alarm 1
Bit 5 1 = Channel 14 Alarm 1 0 = Channel 14 no Alarm 1
Bit 4 1 = Channel 13 Alarm 1 0 = Channel 13 no Alarm 1
Bit 3 1 = Channel 12 Alarm 1 0 = Channel 12 no Alarm 1
Bit 2 1 = Channel 11 Alarm 1 0 = Channel 11 no Alarm 1
Bit 1 1 = Channel 10 Alarm 1 0 = Channel 10 no Alarm 1
Bit 0 1 = Channel 9 Alarm 1 0 = Channel 9 no Alarm 1
Low Byte
Bit 7
1 = Channel 8 Alarm 1 0 = Channel 8 no Alarm 1
Bit 6 1 = Channel 7 Alarm 1 0 = Channel 7 no Alarm 1
Bit 5 1 = Channel 6 Alarm 1 0 = Channel 6 no Alarm 1
Bit 4 1 = Channel 5 Alarm 1 0 = Channel 5 no Alarm 1
Bit 3 1 = Channel 4 Alarm 1 0 = Channel 4 no Alarm 1
Bit 2 1 = Channel 3 Alarm 1 0 = Channel 3 no Alarm 1
Bit 1 1 = Channel 2 Alarm 1 0 = Channel 2 no Alarm 1
