AMT Datasouth 6000 User Manual
Page 26
Fastmark 6000 Series
User's Guide 25
Figure 21 - Media Routing
17. Rotate the Side Access Door up to close.
18. Rotate the green Print Head Latch clockwise fully to lock the printhead and Side
Access Door shut.
Upper Media Sensor Arm
Lower Media Sensor Arm
Front Media Rail
Back Media Rail
Media
Side Access Door
