20 User's Guide Fastmark 6000 Series
Loading Media
1. Fully open Top Access Cover.
2. Open the Front Access Door by rotating down.
Figure 16 - Open Top Access Cover
3. Rotate the green Printhead Latch counterclockwise to open the printhead.
4. Rotate the Side Access Door down to allow the media to be loaded under the printhead
module.
Figure 17 - Printhead Latch and Side Access Cover
Printhead Latch
Side Access Latch
Top
Access
Door
Front Access
Door
