IS 50-LO plus / IGA 50-LO plus Manual
Introduction 9
2 Introduction
2.1 Appropriate use
The pyrometers IS 50-LO plus and IGA 50-LO plus are digital, highly accurate pyrometers with
fiber optics for non-contact temperature measurement on metals, ceramics, graphite etc.
between 250 °C and 3500 °C.
The IS 50/055-LO plus and IS 50/067-LO plus are special versions with extremely short
wavelengths where e.g. molten metal has a very high emissivity.
The instrument type IS 50-Si-LO plus is optimized for measurements on silicon wafers, e. g. in
vacuum chambers.
The IS 50-Al-LO plus is specially designed for measurements on aluminium parts and profiles.
2.2 Scope of delivery
Converter, mono fibre 2.5 m, one selectable optical head (please specify when ordering), works
certificate, InfraWin operating and analizing software, user manual.
Note: A connection cable is not included with the instrument and has to be ordered
separately (see Chapter 10, Reference numbers).
2.3 Technical data
Temperature Ranges:
IS 50-LO plus
IS 50/055-LO plus
IS 50/067-LO plus
IS 50-AI-LO plus
IS 50-Si-LO plus
IGA 50-LO plus
550 ... 1400 °C (MB 14)
600 ... 1600 °C (MB 16)
650 ... 1800 °C (MB 18)
550 ... 1800 °C (MB 18L)
750 ... 2500 °C (MB 25)
900 ... 3300 °C (MB 33)
1000…2300 °C (MB 23)
1100…3500 °C (MB 35)
400 ... 1000 °C (MB 10)
400 ... 1300 °C (MB 13)
500 ... 1600 °C (MB 16)
300 ... 1300 °C (MB 13)
350 ... 1800 °C (MB 18)
450 ... 2500 °C (MB 25)
250 ... 1350 °C (MB 13.5L)
300 ... 2000 °C (MB 20L)
350 ... 2500 °C (MB 25L)
Temperature Subrange: Any range adjustable within the temperature range, minimum span
51 °C
