IS 50-LO plus / IGA 50-LO plus Manual Introduction 10
Spectral Ranges: IS 50-LO plus: 0.7 ... 1.1 µm
IS 50/055-LO plus: 0.55 µm
IS 50/067-LO plus: 0.676 µm
IS 50-Si-LO plus &
IS 50-Al-LO plus:
narrow band in the near infrared
IGA 50-LO plus: 1.45 ... 1.8 µm
Signal Processing: Photo current, digitized immediately
Detector: IS 50-LO plus; IS 50/055-LO plus; IS 50/067-LO plus; IS 50-Si-LO plus;
IS 50-Al-LO plus: Si
IGA 50-LO plus: InGaAs
Power supply: 24 V AC or DC (12 … 30 V AC or DC) (AC: 48 … 62 Hz)
Power consumption: Max. 2 W
Analog output: 0 … 20 mA or 4 … 20 mA (linear), switchable; load: 0 … 500
Test current output: Fixed 10 mA (for 0 … 20 mA analog output) or
fixed 12 mA (for 4 … 20 mA analog output)
Serial interface: RS232 or RS485 addressable (half duplex), switchable, baud rate 1.2
up to 115 kBd
Resolution: Interface and display: 0.1°C
Analog output: < 0.1 % of the adjusted temperature range
Isolation: Power supply, digital interface, analog output are galvanically
isolated against each other
Display: Illuminated LC display for temperature indication or parameter
settings
Parameters: Adjustable at the instrument or via serial interface: emissivity;
response time; analog output; address; baud rate; waiting time; °C or
°F; setting of the maximum value storage; temperature sub range
Emissivity :
20 … 100% adjustable inside the instrument or via interface in steps
of 0.1%
Exposure time t
90
: < 1 ms; adjustable to 0.01 s; 0.05 s; 0.25 s; 1 s; 3 s; 10 s
Maximum value
storage: Single or double storage; cleared by: preselected time interval or
external deletion contact or via digital interface or automatically
with the next measuring object
Switch contact: Max. 0.15 A (to recognize a hot object in the measuring beam.
Contact switches if the measuring temperature is minimum 1% above
the beginning of the temperature range (only active with automatic
clearing or t
CL
< 0.5 s))
Sighting: Laser targeting light (class 2, max. power level
< 1 mW, = 630-680 nm)
Meas. Uncertainty*:
( = 1, t
90
= 1 s, T
amb.
= 23 °C)
Up to 1500 °C: 0.3% of reading in °C + 1 °C
Above 1500 °C: 0.5% of reading in °C
Repeatability:
( = 1, t
90
= 1 s, T
amb.
= 23 °C)
0.1% of reading in °C + 1 °C
Ambient temperature: IS 50-LO plus;
IGA 50-LO plus:
IS 50-Si-LO plus;
IS 50-Al-LO plus:
0 ... 60 °C on the converter, up to 250 °C on side
of fiber and optical head
20 ... 30 °C on the converter, up to 250 °C on
side of fiber and optical head
(The laser targeting light switches off automatically if the internal temperature of the
instrument goes above 55 °C, above 70 °C at the 4 ... 20 mA output a thermo switch
sets the analog output to 0 mA)
