IS 50-LO plus / IGA 50-LO plus Manual Reference Numbers 33
10 Reference Numbers
10.1 Reference numbers instrument
Pyrometer Temperature Range Reference Number
IS 50-LO plus
550 … 1400 °C (MB 14) 3 882 500
600 … 1600 °C (MB 16) 3 882 520
650 … 1800 °C (MB 18) 3 882 540
750 … 2500 °C (MB 25) 3 882 560
900 … 3300 °C (MB 33) 3 882 580
550 … 1800 °C (MB 18L) 3 882 600
IS 50/055-LO plus 1000 … 2300 °C (MB 23) 3 882 680
IS 50/067-LO plus 1100 … 3500 °C (MB 35) 3 882 690
IS 50-Si-LO plus
400 ... 1300 °C (MB 13) 3 882 660
500 ... 1600 °C (MB 16) 3 882 640
IS 50-Al-LO plus 400 ... 1000 °C (MB 10) 3 882 840
IGA 50-LO plus
300 … 1300 °C (MB 13) 3 882 700
350 … 1800 °C (MB 18) 3 882 720
450 … 2500 °C (MB 25) 3 882 740
250 … 1350 °C (MB 13,5L) 3 882 760
300 … 2000 °C (MB 20L) 3 882 780
350 … 2500 °C (MB 25L) 3 882 800
Scope of delivery:
Converter, mono fiber 2.5 m, one selectable optical head (please specify when ordering), works
certificate, InfraWin operating and analizing software, user manual.
Ordering notes:
When ordering please select one optical head (see Section 3.4 Optics).
A connection cable is not included with the instrument and has to be ordered separately.
10.2 Reference numbers accessories
Replacement optical head type I
3 873 320
measuring distance 120 mm
3 873 340 measuring distance 260 mm
3 873 350 measuring distance 700 mm
Replacement optical head type II:
3 873 420
measuring distance 87 mm
3 873 440 measuring distance 200 mm
3 873 460 measuring distance 600 mm
3 873 470 measuring distance 4500 mm
Replacement optical head type II, focusable:
3 838 210
measuring distance 88 … 110 mm
3 838 220 measuring distance 95 … 129 mm
