Warning, Ratings and specifications, Warnings – Hired-Hand Feed Management System User Manual
Page 3
Part No. 4801-2998 Rev 6-04
FEED MANAGEMENT SYSTEM
Page 3 of 15
1. Ratings and Specifications
HHI Part
Number
Description
Power Supply
Temperature
Sensing Range
6407-6036
Feed Bin Level Sensor
12Vdc, 100mA
0 thru 30.67 ft.
6407-6070
Current Sensor
1.5 Vdc @ 120 mA
0° F thru 130°F
(-18° C thru +54° C)
.35 thru 100A AC
2. Warnings
Warning!
Only a certified electrician should install or maintain electrical connections.
Warning!
Proper safety equipment must be used during installation of Feed Level Monitor.
Warning!
Do not install or maintain equipment during a lightning storm.
Warning!
Maximum operating temperature of Feed Level Sensor is -18
° to +54° C (0° to 130° F).
Warning!
When this system is used in a life sustaining application where failure could result in
loss or injury, the user should provide adequate back-up, or accept the risk of such
loss or injury!
