Specifications
51
8.0
Specifications
Pressure Specifications:
Pressure range:
Three independent pressure ranges per
instrument. See “Part Number System” on
page 36 for available ranges
Available Pressure
Calibrations:
Gage only, absolute only, or
gage and absolute
Overall Accuracy:
< ±0.05% Full Scale Max. Accuracy
statement includes all effects of linearity,
hysteresis, repeatability and ambient
temperature
Operating Temperature: +40° to +122°F (+4.4° to +50.0° C)
Storage Temperature:
0° to +185° F (–17.8° to +85°C)
Pressure Media:
Dry gaseous nitrogen, standard
Internal Pressure Cylinder:
Capacity:
7.0 ft
3
N
2
@ 2216 PSIG
Volume:
80 in
3
Rating:
2216 PSIG
Test Pressure:
3360 PSIG
Material:
6061 Aluminum
Pressure Supply Gage:
Size:
2-in. diameter
Range:
0–3000 PSIG
Test Pressure:
4500 PSIG
Over-pressure Rupture Disk:
Rating:
3000 PSIG, nominal
Type:
Stainless steel outer case
Pressure Media Filter:
Rating:
20 microns, Test Port
Type:
Field replaceable
Orion-2C Control Valve:
Type:
Micro-metering with replaceable soft seat
Material:
Aluminum body, clear anodized aluminum
knobs, black anodized. All other parts 300
series stainless steel
Relief Valve:
Type:
Adjustable, atmospheric bleed
Setting:
Adjustable to 10% above highest
calibrated pressure
Material:
300 series stainless steel
Internal Piping:
Tubing:
1/8 in. O.D., 0.030 in. wall thickness
seamless Cu
Couplings:
Brass, Swagelok type
Fill Port:
Style:
Quick-disconnect.
Pressure Rating:
3000 PSIG connected, 2000 PSIG
disconnected
Material:
300 series stainless steel
Test Port:
Pressure Rating:
5000 PSIG
Material:
300 series stainless steel
Vent Port:
Style:
1/4" 37° AN male
Pressure Rating:
2500 PSIG
Material:
Brass
Pressure Hoses:
Quantity Supplied:
Two; one input, one output
Length:
5 ft. nominal, each hose
Style:
Fill (input) hose - Nylon-lined core tube with
synthetic braid, polyurethane cover. Fitted
with quick-disconnect (Brass) socket on
one end and 1/4" 37˚ female AN swivel
pressure fitting on opposite end
Test Port (output) hose - Nylon-lined core
tube with synthetic braid, polyurethane
cover. Fitted with quick-disconnect plug
(St Stl) on one end and 1/4" 37˚ female AN
swivel tube coupling on the other
Pressure Limit Control Regulator:
Type:
Single stage, self-venting, non-bleed
Pressure Rating:
3000 PSIG max. inlet
Internal Pressure Sensor:
Type:
Bonded, metal foil strain gage, sputtered
thin-film or equivalent
Sensitivity:
3 mV/V nominal
Construction:
Completely weld-sealed stainless steel
outer body and pressure cavity
Battery:
Type:
Rechargeable, lead-acid gel
Nominal Voltage:
12V
Approx. Weight:
2.86 lbs
Case:
Polystyrene/H.I. ABS
Carrying Case UPC5000 only:
Type:
Aluminum case with latched cover and
handle
Material Thickness:
0.090 in., nominal
Finish:
Enamel paint, textured finish
Color:
Gray
Control Panel:
Material:
Aluminum (5052-H32)
Thickness:
0.125 in
Finish:
Gray enamel paint with black silkscreen
nomenclature
Physical Specifications:
Weight:
34 lbs. including all hoses and cables
UPC5000 Case Dim’s:
10" wide x 16" long x 11.5" high
UPC5010 Case Dim’s:
19" wide x 8.1" deep x 10.5" high
(Case dimensions excluding front handles)
