Maintenance and Service

21

16. To adjust the

VENT

valve, follow Steps 3 and 4 above.

17. Close the

COARSE

valve by turning the

COARSE

knob (*2) clockwise.

18. Close the

VENT

valve knob insert (4) clockwise until slightly snug.

19. With the supply pressure at 100% of full scale, open the

COARSE

valve until the indicated pressure

stabilizes and then close the

COARSE

valve.

20. Slowly turn the

VENT

valve knob insert (4) counter-clockwise until the display starts to decrease, then

turn the knob insert (4) slightly until the indicated pressure stops decreasing.

21. Follow steps 10 through 15 replacing the term

COARSE

valve with

VENT

valve. The

VENT

valve is now

adjusted.

4.2.11

Pressure Limit Control (Standard Pneumatic), Regulator Removal

Tools required:

Phillips screwdriver
7/16" open end wrench
9/16" open end wrench
A/R 1/4" wide Teflon tape, (PN 60575)

A/R 1/2" wide Teflon tape, (PN 60911)

1/2" socket
socket wrench
1/4" hex wrench

NOTE:

See Figure 4-2 on page 35 for additional parts information.

1. Vent any remaining gas from the nitrogen cylinder to atmosphere. Disconnect the power cord from the

power source.

2. Remove front panel from its enclosure as described in Section 4.2.1 on page 14, and carefully place on a

bench top.

3. Remove regulator knob cap and the two screws that secure the round plate.

4. Loosen and remove the locknut using a 1/2" socket while holding the knob. Remove the knob by turning

counter-clockwise

5. Remove all tubing sections that connect to the regulator inlet and outlet fittings.

6. Loosen the mounting collar in the panel rear using a 1/4" hex wrench.

7. Remove the regulator by sliding out from the panel rear.

8. Mount the regulator in a bench vise by the flats in the base.

9. Note the orientation of the inlet and outlet fittings in the regulator. Remove the fittings and any remnants

of Teflon tape from the pipe threads.

4.2.12

Pressure Limit Control (Standard Pneumatic), Regulator Installation

Tools required:

Phillips screwdriver
7/16" open end wrench
9/16 " open end wrench
A/R 1/4" wide Teflon tape, (PN 60575)

A/R 1/2" wide Teflon tape, (PN 60911)

snoop, liquid leak gas detector (PN 64781)
1/2" socket
socket wrench

NOTE:

See Figure 4-2 on page 35. Call CONDEC for replacement part numbers.

1. Wrap two layers of Teflon tape on the pipe threads of each fitting and install into the inlet and outlet of

the regulator and ensure that each is oriented properly. Use a bench vise when doing this.

Insert the new regulator into the panel through hole. Pass the adjusting end through the mounting ring.

NOTE:

Do not tighten cap screw until adjusting knob is installed.

2. Install the tubing sections to the inlet and outlet fittings.
