A p p l i c a t i o n 2 7

Wa t l o w M

I N I

C

H E F

2 0 0 0

3

Configuration Mode Quick Reference

These are the functions, parameters and values included in the Configuration Mode for
this application. You must select Application 27 to access them. For directions, see the
Hardware & Software Setup Guide. The Appendix of that guide includes an explanation
of all parameters and values.

Function

Parameter

Value

Your Settings

[Etype] Equipment-Type

[appl`] Application

1 - 28

27

[a_Loc] Application Number

Yes, No

Security Lock

[StEPS] Number of cooking steps

1, 2

[ProbE] Probe

Yes, No

[SEtUP] Setup

[`З_П`] Temperature Display Units

°C or °F

[time] Time Display Units

MMM:SS, HH:MM, H:MM:SS

[Chirp] Key Chirp

On, Off

[loc``] Menu Security Lock

Yes, No

[tc```] Thermocouple Type

J, K (shown as [````H]), E

[rtd``] RTD Curve

DIN, JIS

[tconp] WatCurve

TM

On, Off

Temperature Compensation

[0fst1] Temp Offset, Channel 1

-99 to 99°F (-55 to 55°C)

[0fst2] Temp Offset, Channel 2

-99 to 99°F (-55 to 55°C)

[tr`lo] Temperature Range Low

0ºF (-18ºC) for RTD inputs

32ºF (0ºC) for tc inputs to [tr`Hi]

[tr`Hi] Temperature Range High

[tr`lo] to 1200ºF (649ºC)

[ready] Preheat Ready Feature

Yes, No

[rband] Ready Band

1 to 1200°F (1 to 649°C)

[Cloc`] Real Time Clock Display

Yes, No

[plOSS] Power Loss Menu Resume

Yes, No

[al``1] Alarm 1

None, Dev, Proc, Both

[aL`P1] Absolute Process Alarm 1

100 to 1200°F (38 to 649°C)

[aLdL1] Low Deviation Alarm 1

-999 to 0°F (-555 to 0°C)

[aLdH1] High Deviation Alarm 1

0 to 999°F (0 to 555°C)

[al``2] Alarm 2

None, Dev, Proc, Both

[aL`P2] Absolute Process Alarm 2

100 to 1200°F (38 to 649°C)

[aLdL2] Low Deviation Alarm 2

-999 to 0°F (-555 to 0°C)

[aLdH2] High Deviation Alarm 2

0 to 999°F (0 to 555°C)

[tHErl] Thermal

[tyPE`] Temperature Control Type

Pid, On-Off

[HYSt1] Hysteresis 1

1 to 99°F (1 to 55°C)

[Pid`U] PID Units

SI, US

[tune1] Auto-tuning 1

on, OFF

[ProP1] Proportional Band 1

1 to 999°F (1 to 555°C)

[rSEt1] Reset (integral) Gain 1

0.00 to 9.99 repeats/minute

[Int`1] Integral Gain 1

0.00 to 99.99 minutes/repeat

[rAtE1] Rate (derivative) Gain 1

0.00 to 9.99 minutes

[dEr`1] Derivative Gain 1

0.00 to 9.99 minutes

[CYcL1] PID Cycle Time 1

1 to 60 seconds

[[`diag] WatHelp

Used for equipment troubleshooting and testing. Not used when programming. See the Hardware

Diagnostics

& Software Setup Guide.
