1 4 ■ Wa t l o w M I N I C H E F 2 0 0 0 A p p l i c a t i o n 2 8
Key Functions in Configuration Mode
Key Functions in Operation Mode
ç
WARNING: The Jog and Increment keys cause or initiate machine motion. Appropriate reasonable care should be
taken to prevent personal injury or machine damage as a result of operator initiated or unexpected machine motion.
Summary of Input/Output Functions
Note: For details, see wiring instructions in the Hardware & Software Setup Guide.
Heat
Set
temp(s)
Set
time(s)
Start/Stop
Down
Probe
temp
Your Company Logo
U p
J o g
Input 1 Oven Temperature
→
Input 2 Probe Temperature
→
Event Input 1 Door Open
→
Event Input 2 not used
→
→
Output 1 Heat
→
Output 2 not used
→
Event Output 1 Spit Motor Control
→
Event Output 2 Fan
→
Output 5 Audible Alarm
Hold
Temp
Heat
Temp Time
Up
Jog
Hold
Temp
Start/Stop
Down
Your Company Logo
Heat Indicator Light Lit
when heat output is on.
Temp Setpoint 1
Temperature
Time Set Time 1
Hold Temp Set the Hold
Setpoint.
Jog and Increment
Jog the spit and scroll
through valid menus
Start/Stop Activate or
cancel active menu
Probe and Decrement
Probe or scroll through
valid menus
Start/Stop Indicator Light
Slow flash...Preheating
Rapid flash...Ready
Lit...Cooking
Off...Done
Probe
Temp
A B
D E
G H
Enter
Escape Home
Edit
C
F
M
INI
C
HEF
2000
Display five-digit, seven-
segment numeric LED
display.
Indicator lights
(1 for each key, 2 for heat
channels).
Edit key (A) Access the
next level of parameters or
values.
Enter key (B) Enter the
value and return to
previous level.
Home key (D) Move to
Operation Mode with a
two-second key press.
Up key (C) Move up the
lists.
Escape key (E) Return to
original value when editing
a parameter value.
Down key (F) Move down
the lists.
