Application 27
Manual and Automatic
Rotisserie Oven

One Heat Channel, 30 Pre-programmed Menus, One Manual Menu

Introduction to Application 27 . . . . . . . . . . . . . . 1
Configuration Mode Quick Reference . . . . . . . . . 3
Program Mode Quick Reference . . . . . . . . . . . . 4
Step 7 Design a Faceplate Overlay . . . . . . . . . . . 5
Step 8 Operate the Controller . . . . . . . . . . . . . . 6

Application 27 allows you to program as many as thirty menus to control one temperature
channel and cooking time for an automatic cook-&-hold oven. The oven may also be pro-
grammed manually by the operator. The oven includes a probe function for temperature
sensing, a spit output and a fan output.

Overview of Key Steps

1.

Install the M

INI

C

HEF

2000.

2. Wire the controller.

3. Configure the controller.

4. Program the menus.

5. Set the controller security.

6. Set the Real-time Clock.

For instructions on Steps 1, 2, 3, 4, 5 and 6, see the Hardware & Software Setup Guide.

7. Design, manufacture and apply faceplate overlay for end-users. (For a suggested design

to suit this application, see this section. For overlay dimensions and guidelines, see the
Hardware & Software Setup Guide.)

8. Operate the controller. (See this application guide.)
