Chapter 3. Operation
3-10 TSU 120 User Manual 61202129L1-1
Alternate Methods of Control
T-WATCH Pro (ADTRAN PC Program)
T-WATCH Pro is the ADTRAN PC control program. It provides
complete control over the configuration of the TSU 120 using a
graphical interface. The T-WATCH Pro program displays the
same status and performance data as the front panel LCD. This
data is displayed in the form of tables and graphs.
The T-WATCH Pro program has the following capabilities:
• Interfaces with a modem which permits dialing into a re-
mote TSU 120 location to configure the unit or read the sta-
tus or performance of the unit.
• Receives traps from any TSU product.
• Records and creates display performance data over a 30-
day period.
• Accesses units via the local area network (TSU 120e only).
T-WATCH Pro/LAN Connection
To set up the TSU 120 to work with T-WATCH Pro over the
LAN, follow these steps:
Step Action
1 Set the Unit ID using the front panel. See Unit ID on
page 6-4 for details.
2 Set C ONTROL P ORT interface to N ORMAL using the
Front Panel
3 Configure the IP ADDRESS , DEFAULT GATEWAY , and
SUBNET MASK using the front panel.
4 Follow the installation instructions for T-WATCH Pro
to start the program and connect to the unit.
