Chapter 3. Operation
3-6
TSU 120 User Manual
61202129L1-1
Select and Activate a Menu Item
To choose menu items, place the cursor on the desired menu
item by pressing the number corresponding to the menu item
or highlighting the menu item with the
up
and
down arrow
.
Activate the
A
LARM
L
IST
option from the
S
TATUS
M
ENU
by
using the following steps.
.
Figure 3-2. Example of Basic Front Panel Menu Tree
Step
Action
1
Activate the
STATUS
MENU
using the
arrow keys
or by
pressing
1
. The cursor will flash on the number next
to the activated selection.
2
Press
Enter
.
3
View the submenu items by using the
arrow keys.
4
Choose an item on the submenu such as
ACTIVE
ALARMS
.
5
Select the submenu with the
Arrow Keys
or by
pressing
3
.
6
Press
Enter
.
7
View the Alarm List by using the
arrow keys
.
1) NI PERF RPTS
2) NI ERRORS
3) ACTIVE ALARMS
(ALARM LIST)
4) VIEW HISTORY
END OF LIST
1)STATUS
5) PORT STATUS
6) REMOTE PORT
7) CLEAR PORT ALM
8) ENET STATUS
9) SLIP STATUS
