ADTRAN TSU 120e User Manual
Page 120

Appendix C. Network Pinouts
C-2
TSU 120 User Manual
61202129L1-1
Control In/Chain In
This is used as an EIA-232 port for connection to a computer or
modem (Control In) or to another TSU 120 or TSU 100 (Chain
In). See Table C-2 for the pinout for the control/chain-in connec-
tor.
Connections
The chain-in connections are as follows:
Connector type
RJ-48
Part number
AMP# 555164-2
Table C-2. Control In/Chain in Pinout
Pin
Name
Description
1
GND
Ground - connected to unit chassis
2
RTS
Request to send - flow control
3
RXDATA
Data received by the TSU 120
4
UNUSED
5
TXDATA
Data transmitted by the TSU 120
6,7
UNUSED
8
CTS
Clear to send - flow control
