Chapter 3. Operation
61202129L1-1 TSU 120 User Manual 3-7
Set the Data Field
You can edit data fields preceded by a colon (:).
Display Only Data Fields
Data fields preceded by an equal (=) symbol cannot be edited.
See Figure 3-3.
Figure 3-3. Display and Data Fields
Press Enter to move the cursor to the data field. Use arrows to
select AUTO and press Enter . The unit automatically sets the
Line Build Out. The display field shows the value actually set.
Step Action
1 Position the cursor on the submenu item number, and
press
Enter . The cursor moves to the data field, (to the
right of the submenu item name).
2 Using the Arrow Keys , scroll to scan the available value
settings. The value settings display one at a time in the
data field position.
3 When the desired value is displayed in the data field
position, press
Enter to set that value. When the value
is set, the cursor moves back to the submenu item
position indicating the operation is complete.
4 Select another submenu field, or press Cancel to return
to the submenu.
5 Press Cancel before pressing Enter to void any data
changes. The original data value is restored and the
cursor returns to the submenu field.
Data Field
Display Field
