Chapter 8. Telnet/Terminal Menus
8-2 TSU 120 User Manual 61202129L1-1
Status, Config, Util, and Test Menu Options
These menu items can access the same modified menus that
you can access through the front panel. For detailed informa-
tion on the available menu options, refer to the following sec-
tions:
• Status Menu on page 4-1
• Configuration Menu on page 5-1
• Utility Menu on page 6-1
• Test Menu on page 7-1
DS0 Maps Configuration Menu
The Telnet/Terminal version of the DS0 maps configuration
menu takes advantage of the 24-line VT 100 display. Upon
entering this menu, the current Temp (temporary) map dis-
plays and is followed by nine selections that you can use for
configuring and reviewing map information. See Figure 8-2
Figure 8-2. DS0 Temp Map
TEMP MAP
DS0# PORT DS0# PORT
1
2
3
4
5
6
7
8
9
10
11
12 IDLE
IDLE
IDLE
IDLE
IDLE
IDLE
IDLE
IDLE
IDLE
IDLE
IDLE 13
14
15
16
17
18
19
20
21
22
23
24 IDLE
IDLE
IDLE
IDLE
IDLE
IDLE
IDLE
IDLE
IDLE
IDLE
IDLE
IDLE
1) COPY MAP A TO TEMP MAP
2) COPY MAP B TO TEMP MAP
3) CREATE TEMP MAP
4) REVIEWMAP A
5) REVIEW MAP B
6) REVIEW TEMP MAP
7) EDIT TEMP MAP
8) APPLY TEMP MAP TO MAP A
9) APPLY TEMP MAP TO MAP B
