ADTRAN TSU 120e User Manual
Page 124
Appendix C. Network Pinouts
C-6
TSU 120 User Manual
61202129L1-1
10BaseT (TSU 120e only)
10BaseT is used to connect the TSU 120 to the local area net-
work. See Table C-6.
Connections
The required wiring connections are:
Connector type (USOC)
RJ-45
Part number
AMP # 555164-1
Table C-6. 10BaseT Ethernet (TSU 120e only)
Pin
Name (TO NIC)
Pin1
TX1
Pin 2
TX2
Pin 3
RX1
Pin 6
RX2
