PS-3650A/PS-3651A Series Hardware Manual
4-10
(5) Unscrew the screws (6) as the figure below indicates.
(6) Open the PS-A unit as the figure below indicates.
(7) Disconnect the Backlight Unit cable from the connector on the inverter board. Remove the cable from
the cable clamp.
Backlight Unit
Connector
Cable Clamp
Cable
