Chapter 3 Installation and Wiring
3-15
(4) Remove the DISK cover.
(5) Mount the HDD unit vertically on the circuit board and plug the HDD unit cable connector in the Serial
ATA interface.
(6) Attach the HDD unit with the screws (4) which are contained in your package. The torque required to
tighten these screws is 0.5 to 0.6 N•m.
(7) Reversing the steps above, return the DISK cover, Expansion Board Base, and Expansion Board Cover
to the PS-A unit, respectively. The torque required to tighten these screws is 0.5 to 0.6 N•m.
• Be sure to mount the HDD unit slowly and vertically and not to hit the circuit board
with the HDD unit. Contact may cause a malfunction or damage the HDD unit and
PS-A unit.
Serial ATA Interface
