Chapter 2 Specifications
2-15
System Set SW 1
Change Hardware Reset Switch mode
*1
•
Power button mode
When the Hardware Reset Switch on the front of the PS-A unit is pressed, the Windows
®
power button
operation setting is executed.
For Windows
®
XP, the option selected in [When I press the power button on my computer] from [Control
panel]-[Power Options]-[Advanced] occurs.
•
Reset SW mode
The PS-A unit restarts when pressing the Hardware Reset Switch on the front of the PS-A unit.
Disable/Enable Hardware Reset Switch
When disabled, you cannot reset using Hardware Reset Switch while the system is running.
When enabled, Hardware Reset Switch operates in the mode set on Switch No.3.
SW No.
Description
ON
OFF
Notes
1
Used for the system.
Reserved
Reserved
Factory Settings: ON
2
Used for the system.
Reserved
Reserved
Factory Settings: OFF
3
Change Hardware Reset
Switch mode.
Power
button
Reset SW
Factory Settings: OFF
4
Disable/enable Hardware
Reset Switch.
Disabled
Enabled
Factory Settings: OFF
5
Used for the system.
Reserved
Reserved
Factory Settings: OFF
6
Disable/enable Access to the
Front USB port.
Disabled
Enabled
Factory Settings: OFF
7
Used for the system.
Reserved
Reserved
Factory Settings: OFF
8
Disable/enable Detecting the
middle point during touching
two points simultaneously.
Disabled
Enabled
Factory Settings: OFF
9
Used for the system.
Reserved
Reserved
Factory Settings: OFF
10
Changes COM1's # 9 pin
(RI <---> +5V).
Enabled only when RS-232C
mode
+5V
Output
RI
Factory Settings: OFF
Table 1) System Set SW 1
*1
In SOFT OFF state, pressing Hardware Reset Switch will start the PS-A unit regardless of settings.
For more details about SOFT OFF state, please refer to 1.4.2 Power Supply (page 1-7).
