Proface APL3000B - Node Box PC User Manual
Page 18

Chapter 1 Overview
1-5
F: Power Switch
AC Power Supply Type only
G: Power Supply Connector
For connection, attach a power plug (included) to the
power cable.
H: Mask Cover
I: Expansion Board Base
J: Expansion Board Cover
K: Expansion Board Support
L: Fan Unit
M: Memory Slot Cover
N: DISK Cover
I
Rear
(PS-3651A Series AC Power Supply Type)
I
Rear
(PS-3650A Series DC Power Supply Type)
N
Rear
(PS-3651A Series DC Power Supply Type)
I
J
K
F
G
H
L
M
Rear
(PS-3650A Series AC Power Supply Type)
I
J
K
G
H
L
F
G
H
N
M
G
H
