Initiate programming of Print Header by pressing <9> and then . The display

shows the beginning information for the printer header. If your header has not been

programmed or has been cleared, the cursor will prompt you for your first character entry.

(Refer to Table: Print Header Character Codes, at the end of Mode 11 description, for

a numeric code which represents the characters available for your use on the printer

header.) Determine the character you wish to place in the first position of the header and

look up the numeric code. Enter this numeric code on the keypad and press .

The character will appear on the display, and has been saved in memory. For each

subsequent character, follow the sequence described above.

There are two special numeric codes for the header: <10> indicates a new line in the

header; <01> is the code for end of header. Enter the new line code at the point where

the printer should cease printing on the current line and go to the beginning of the next

line. The end of header code is entered after the entire header is entered and will tell the

PIcon that no more characters are needed in the header.

Special editing features are available for use under Print Header:

without entering a numeric code — The display cursor will increment to

the next character in the header.
