4.3.9 H/W Monitor
The H/W Monitor menu (BIOS Menu 13) shows the operating temperature, fan speeds
and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Temperature :+58 °C
Environment Temperature 1 :+63 °C
Environment Temperature 2 :+39 °C
SYS Temperature :+38 °C
CPU FAN Speed
:648 RPM
Fanless Temp. Overwrite Control [Enabled]
Temperature Of FANLess
[32 C]
Fanless Temperature Reading :+32 °C
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 13: Hardware Health Configuration
Î Hardware Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
ƒ System Temperatures:
o CPU Temperature
o Environment Temperature
o System Temperature
ƒ Fan Speeds:
o CPU Fan Speed
Î Fanless Temp. Overwrite Control [Enabled]
Use the Fanless Temp. Overwrite Control BIOS option to enable or disable
Temperature of Fanless configuration.
