IEI Integration AFL2-15A-H61 - Manual (Page 79)

AFL2-15A-H61
Page 62
Î
Auto D EFAULT The serial port IO port address and interrupt
address are automatically detected.
Î
IO=3E8h; IRQ=7 Serial Port I/O port address is 3E8h and the
interrupt address is IRQ7
Î
IO=3F8h; IRQ=3,
4,5,6,7,10,11,12
Serial Port I/O port address is 3F8h and the
interrupt address is IRQ3, 4, 5, 6, 7, 10, 11, 12
Î
IO=2F8h; IRQ=3,
4,5,6,7,10,11,12
Serial Port I/O port address is 2F8h and the
interrupt address is IRQ3, 4, 5, 6, 7, 10, 11, 12
Î
IO=3E8h; IRQ=3,
4,5,6,7,10,11,12
Serial Port I/O port address is 3E8h and the
interrupt address is IRQ3, 4, 5, 6, 7, 10, 11, 12
Î
IO=2E8h; IRQ=3,
4,5,6,7,10,11,12
Serial Port I/O port address is 2E8h and the
interrupt address is IRQ3, 4, 5, 6, 7, 10, 11, 12
Î
IO=2E0h; IRQ=3,
4,5,6,7,10,11,12
Serial Port I/O port address is 2E0h and the
interrupt address is IRQ3, 4, 5, 6, 7, 10, 11, 12
Î
IO=2F0h; IRQ=3,
4,5,6,7,10,11,12
Serial Port I/O port address is 2F0h and the
interrupt address is IRQ3, 4, 5, 6, 7, 10, 11, 12
Î Device Mode [RS422]
Use the Device Mode option to select the serial port mode.
Î
RS422 D EFAULT Enables serial port RS-422 support.
Î
RS485 Enables serial port RS-485 support.
