AFL2-15A-H61

Page 135

8.2.20 Speaker Connector (SPK_CN13)

8.2.21 SPI Flash Connector (JSPI1)

8.2.22 EC SPI Flash Connector (JSPI2)

PIN NO.

DESCRIPTION

1 SPK_OUT_P_L

2 SPK_OUT_N_L

3 SPK_OUT_N_R

4 SPK_OUT_P_R

Table 8-21: Speaker Connector (SPK_CN13) Pinouts

PIN NO.

DESCRIPTION

1 SPI_VCC

2 SPI_CS#0_CN

3 SPI_SO0_CN

4 SPI_CLK0_CN

5 SPI_SI0_CN

6 GND

Table 8-22: SPI Flash Connector (JSPI1) Pinouts

PIN NO.

DESCRIPTION

1 SPI_VCC

2 FSCE#_S

3 FMISO_S

4 FSCK_S

5 FMOSI_S

6 GND

Table 8-23: EC SPI Flash Connector (JSPI2) Pinouts
