IEI Integration AFL2-15A-H61 - Manual (Page 77)

AFL2-15A-H61
Page 60
4.3.8.1.1 Serial Port 1 Configuration
Î Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Î
Disabled Disable the serial port
Î
Enabled D EFAULT Enable the serial port
Î Change Settings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt
address.
Î
Auto D EFAULT The serial port IO port address and interrupt
address are automatically detected.
Î
IO=3F8h; IRQ=4 Serial Port I/O port address is 3F8h and the
interrupt address is IRQ4
Î
IO=3F8h; IRQ=3,
4,5,6,7,10,11,12
Serial Port I/O port address is 3F8h and the
interrupt address is IRQ3, 4, 5, 6, 7, 10, 11, 12
Î
IO=2F8h; IRQ=3,
4,5,6,7,10,11,12
Serial Port I/O port address is 2F8h and the
interrupt address is IRQ3, 4, 5, 6, 7, 10, 11, 12
Î
IO=3E8h; IRQ=3,
4,5,6,7,10,11,12
Serial Port I/O port address is 3E8h and the
interrupt address is IRQ3, 4, 5, 6, 7, 10, 11, 12
Î
IO=2E8h; IRQ=3,
4,5,6,7,10,11,12
Serial Port I/O port address is 2E8h and the
interrupt address is IRQ3, 4, 5, 6, 7, 10, 11, 12
4.3.8.1.2 Serial Port 2 Configuration
Î Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Î
Disabled Disable the serial port
