3.3 Installation and Configuration Steps

The following installation steps must be followed.

Step 1:

Unpack the system

Step 2:

Install a CF card

Step 3:

Configure the system

Step 4:

Connect peripheral devices

Step 5:

Mount the system

Step 0:

3.4 Removing the Back Cover

WARNING:

Over-tightening back cover screws will crack the plastic frame.

Maximum torque for cover screws is 5 kg-cm (0.36 lb-ft/0.49 Nm).

To access the AFL-F08A internally the back cover must be removed. To remove the back

cover, please follow the steps below.
