ECN-360A-HM65 Em b e d d e d S ys te m
P a g e 79
 1920x1080 (48bit)
 1920x1200 (48bit)
 2048x1536 (48bit)
 Backlig h t Co n tro l [No rm a l]
Use the Backlight Control option to select backlight control mode.

Normal D EFAULT Brightest at low voltage level.

Inverted Brightest at high voltage level.
5.5.2 S o u th b rid g e Co n fig u ra tio n
Use the Southbridge Configuration menu (BIOS Menu 18) to configure the Southbridge
chipset.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
SouthBridge Configuration
Auto Power Button Status
[Disable (ATX)]
Restore AC Power Loss
[Last State]
Azalia
[Enabled]
Azalia Internal HDMI codec [Enabled]
Select AC power state
when power is re-applied
after a power failure.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 18: Southbridge Chipset Configuration
 Res to re o n AC Po wer Lo s s [Las t State ]
Use the Restore on AC Power Loss BIOS option to specify what state the system
returns to if there is a sudden loss of power to the system.

Power Off The system remains turned off
