ECN-360A-HM65 Em b e d d e d S ys te m
P a g e 69
 PC He alth Statu s
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o CPU Temperature
o System Temperature
 Fan Speed:
o CPU Fan Speed
o System Fan Speed
 Voltages:
o VCC_core
o +5VS
o +12VS
o +1.5V
o VSB3V
o VBAT
5.3.7.1 S m a rt Fa n Mo d e Co n fig u ra tio n
Use the Smart Fan Mode Configuration submenu (BIOS Menu 11) to configure fan
temperature and speed settings.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU Fan Smart Fan Control [Auto Duty-Cycle Mode]
Temperature 1 60
Temperature 2 50
Temperature 3 40
Temperature 4 30
Duty Cycle 1 85
Duty Cycle 2 70
Duty Cycle 3 60
Duty Cycle 4 50
SYS Fan Smart Fan Control [Manual Duty Mode]
Manual Duty Mode 100
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 11: Smart Fan Mode Configuration
