ECN-360A-HM65 Em b e d d e d S ys te m
P a g e 47
CN Lo c a tio n : See Figure 4-20
CN P in o u ts : See Table 4-25
The motherboard has two external USB 2.0 ports. The ports connect to both USB 2.0 and
USB 1.1 devices.
Pin Description
1 VCC
2 DATA-
3 DATA+
4 GND
Table 4-25: USB 2.0 Port Pinouts
4.3.4 US B 3.0 Co n n e c to rs
CN La b e l: US B_CON3
CN Typ e : USB 3.0 port
CN Lo c a tio n : See Figure 4-20
CN P in o u ts : See Table 4-26
The USB 3.0 connector can be connected to a USB device.
Pin Description
1 VBUS
2 D1-
3 D1+
4 GND1
5 STDA_SSRX1_N
6 STDA_SSRX1_P
7 GND_DRAIN
8 STDA_SSTX1_N
9 STDA_SSTX1_P
Table 4-26: USB 3.0 Port Pinouts
