u IBX-210-CV-N2600 Em b e d d e d S ys te m
P a g e 71
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Intel IGD Configuration
IGFX - Boot Type [VBIOS Default]
Fixed Graphics Memory Size [128MB]
Auto disable IGD upon
external GFX detected.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 16: Integrated Graphics
 IGFX - Bo o t Typ e [VBIOS Defau lt]
Use the IGFX - Boot Type option to select the display device used by the system when it
boots. For dual display support, select “VBIOS Deafult.” Configuration options are listed
below.
 VBIOS Default D EFAULT
 CRT
 HDMI
 CRT + HDMI
 Fixed Grap h ics Mem o ry Size [128 MB]
Use the Fixed Graphics Memory Size option to specify the amount of memory that can
be allocated as graphics memory. Configuration options are listed below.
 128 MB D EFAULT
 256 MB
6.5.2 S o u th b rid g e Co n fig u ra tio n
Use the Southbridge Configuration menu (BIOS Menu 17) to configure the Southbridge
chipset.
