u IBX-210-CV-N2600 Em b e d d e d S ys te m
P a g e 38
7
MDI2+
8
MDI2-
9
MDI3+
10
MDI3-
11
LINK100
12
LINK1000
13
ACT
14
+V3.3A_LAN1
15
GND
16
GND
Table 4-13: Ethernet Connector Pinouts (LAN1)
4.3.3 HDMI Co n n e c to r (HDMI1)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
HDMI_DATA2
2
GND
3
HDMI_DATA2#
4
HDMI_DATA1
5
GND
6
HDMI_DATA1#
7
HDMI_DATA0
8
GND
9
HDMI_DATA0#
10
HDMI_CLK
11
GND
12
HDMI_CLK#
13
NC
14
NC
15
HDMI_SCL
16
HDMI_SDA
17
GND
18
+5V
19
HDMI_HPD
Table 4-14: HDMI Connector (HDMI1) Pinouts
4.3.4 P o we r Co n n e c to r (DC_J ACK1)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC12V
2
GND
3
GND
Table 4-15: Power Connector Pinouts (DC_JACK1)
4.3.5 RS -232 S e ria l P o rts (COM1, COM2)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
NDCD1/2
2
NRXD1/2
3
NTXD1/2
4
NDTR1/2
