u IBX-210-CV-N2600 Em b e d d e d S ys te m
P a g e 35
5
LPC_AD2
6
LPC_AD1
7
LPC_AD0
8
LPC_FRAME#
9
+3.3V
Table 4-4: Debug port Connector Pinouts (DEBUGCN1)
4.2.4 HDD LED Co n n e c to r (HDDLED1)
4.2.5 J S ATA Co n n e c to r (J S ATA2)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
+12V
3
N/C
4
+12V
5
N/C
6
N/C
7
GND
8
+5V
9
SATA_RX1+
10
+5V
11
SATA_RX1-
12
+5V
13
GND
14
+5V
15
SATA_TX1-
16
GND
17
SATA_TX1+
18
+3V
19
GND
20
+3V
Table 4-6: JSATA Connector Pinouts (JSATA2)
4.2.6 P o we r LED Co n n e c to r (P WRLED1)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
+5V
Table 4-7: Power LED Connector Pinouts (PWRLED1)
PIN NO.
DESCRIPTION
1
SATA_LED#
2
+5V
Table 4-5: HDD LED Connector Pinouts (HDDLED1)
