u IBX-210-CV-N2600 Em b e d d e d S ys te m
P a g e 37
4.3 Exte rn a l In te rfa c e P a n e l Co n n e c to rs
The table below shows a list of the external interface panel connectors on the system
motherboard. Pinouts of these connectors can be found in the following sections.
Co n n e c to r Typ e La b e l
Audio jack (mic-in, line-out) Audio jack JAUDIO1
Ethernet connector RJ-45 LAN1
HDMI connector HDMI HDMI1
Power connector Power jack DC_JACK1
RS-232 serial ports DB-9 COM1, COM2
RS-422/485 serial port 4-pin connector COM3
USB 2.0 connectors USB 2.0 port USB0_1,
USB2_3
VGA connector DB-15 VGA1
Table 4-11: Rear Panel Connectors
4.3.1 Au d io J a c k (J AUDIO1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND_AUDIO 2 LMIC1-CONN-L
3 GND_AUDIO 4 JD_MIC
5 LMIC1-CONN-R 22 LFRONT-L
23 GND_AUDIO 24 JD_FRONT
25 LFRONT-R
Table 4-12: Audio Jack Pinouts (JAUDIO1)
4.3.2 Eth e rn e t Co n n e c to r (LAN1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 MDI0+ 2 MDI0-
3 MDI1+ 4 MDI1-
5 GND 6 GND
