u IBX-210-CV-N2600 Em b e d d e d S ys te m
P a g e 64
 Device Mo d e [RS422]
The Device Mode shows Serial Port 3 provides RS-422/485 communications.

RS422 D EFAULT Enables serial port RS422 support

RS485 Enables serial port RS485 support.
6.3.7 F81866 H/W Mo n ito r
The H/W Monitor menu (BIOS Menu 10) shows the operating temperature, fan speeds
and system voltages.
Aptio Setup Utility – Copyright (C) 2009 American Megatrends, Inc.
Advanced
PC Health Status
CPU temperature
:+44 C
System temperature :+38 C
V_core :+1.048 V
VCC5 :+4.940 V
Vcc12 :+11.660 V
VDDR :+1.512 V
VSB5V :+5.016 V
+V3.3S :+3.376 V
VSB3V :+3.360 V
VBAT :+3.312 V
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 10: Hardware Health Configuration
 PC He alth Statu s
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o CPU temperature
o System temperature
 Voltages:
