u IBX-210-CV-N2600 Em b e d d e d S ys te m
P a g e 39
5
GND
6
NDSR1/2
7
NRTS1/2
8
NCTS1/2
9
NRI1/2
10
Table 4-16: RS-232 Serial Ports Pinouts (COM1, COM2)
4.3.6 RS -422/485 S e ria l P o rt (COM3)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
RXD485+
2
RXD485#
3
TXD485+
4
TXD485#
Table 4-17: RS-422/485 Serial Port Pinouts (COM3)
4.3.7 US B 2.0 Co n n e c to rs (US B0_1)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+5V
2
USB_PN0
3
USB_PP0
4
GND
5
+5V
6
USB_PN1
7
USB_PP1
8
GND
Table 4-18: USB 2.0 Connectors Pinouts (USB0_1)
4.3.8 US B 2.0 Co n n e c to r (US B23)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+5V
2
USB_PN2
3
USB_PP2
4
GND
5
+5V
6
USB_PN3
7
USB_PP3
8
GND
Table 4-19: USB 2.0 Connector Pinouts (USB2_3)
4.3.9 VGA Co n n e c to r (VGA1)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
Red
2
Green
3
Blue
4
NC
