ECW-281B Embedded System
Page 51
(
761H761H761H
Figure 4-8). Ensure that all four of the mounting screws fit snuggly into their
respective slotted holes.
NOTE:
In the diagram below the bracket is already installed on the wall.
Figure 4-8: Mount the Embedded System
4.2.8 DIN Mounting
To mount the ECW-281B/281B2-R20 embedded system onto a DIN rail, please follow the
steps below.
