5.3.4 Hardware Health Configuration
The Hardware Health Configuration menu (BIOS Menu 7) shows the operating
temperature, fan speeds and system voltages.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Hardware Health Event Monitoring
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
FAN1 Mode Setting
[Auto Fan by RPM]
Temperature 1 Limit if Highe [050]
Temperature 1 Limit if Secon [040]
Temperature 1 Limit if Third [030]
Temperature 1 Limit if Lowes [020]
Fan 1 Highest Setting
[100]
Fan 1 Second Setting [080]
Fan 1 Third Setting [070]
Fan 1 Fourth Setting [060]
Fan 1 Lowest Setting [050]
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU Temperature
:74ºC/165ºF
System Temperature :45ºC/113ºF
CPU Fan Speed
:1783 RPM
VCC3
:3.312 V
VCC_Core :1.232 V
VTN_1.5V :1.552 V
VTN2_5V :5.016 V
VTN3_12V :12.320 V
VSB :3.456 V
VBAT :3.056 V
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 7: Hardware Health Configuration
Fan1 Mode Setting [Auto Fan by RPM]
Use the Mode Setting option to configure the fan.
