3.3.3 LAN Connector
CN Label: LAN1, LAN2
CN Type: RJ-45
CN Location: See Figure 3-18
CN Pinouts: See Table 3-18
The LAN connector connects to a local network.
Pin Description Pin Description
1 MDIA3- 5 MDIA1+
2 MDIA3+ 6 MDIA2+-
3 MDIA2- 7 MDIA0-
4 MDIA1- 8 MDIA0+
Table 3-18: LAN Pinouts
3.3.4 Serial Port Connectors (COM1, COM2 and COM3)
CN Label: COM1, COM2, COM3
CN Type: DB-9 connectors
CN Location: See Figure 3-18
CN Pinouts: See Table 3-19 and Figure 3-21
The serial port connects to a RS-232 serial communications device.
Pin Description Pin Description
1 DCD 6 DSR
2 RX 7 RTS
3 TX 8 CTS
4 DTR 9 RI
5 GND
Table 3-19: Serial Port Pinouts
