Defibrillator Specifications
9650-0912-01 Rev. K ZOLL R Series Operator’s Guide A–5
Heart rate accuracy ±5%
Heart rate alarm Screen icon indicates activated/deactivated status. User selectable.
Tachycardia: 60 to 280 beats per minute
Bradycardia: 20 to 100 beats per minute
Tall T-wave Rejection < 0.8 mV
Heart Rate Averaging The R Series averages the interval between the last 5 detected beats.
On startup, the R Series averages the rate between detected beats
once two beats are detected, until a full 5 beats have been received.
The rate is updated every beat. After this condition is met, the meter is
updated every beat with an average of the last 5 beats.
If a period of time greater than 5 seconds elapses without a beat
detected, the heart rate meter reports a rate of 0 bpm, which is
repeated every 5 seconds.
Accuracy and Response
Time to Irregular Rhythm Averaging over 5 R -R intervals, per AAMI EC 13:2002:
• Ventricular bigeminy (Figure 3a) - 80.5 bpm
• Slow alternating ventricular bigeminy (Figure 3b) - 60.5 bpm
• Slow alternating ventricular bigeminy (Figure 3c) - 120.5 bpm
• Bidirectional systoles (Figure 3d) - 93.3 bpm
Response Time to
Change in Heart Rate Average response time: 3.37 seconds
Time to Alarm for
Tachycardia Minimum time to alarm: 3.66 seconds
Maximum time to alarm: 8.41 seconds
Leads Off Sensing A dc current of 0.04 uA per lead wire is supplied to the patient.
Active Noise
Suppression The sum of all leadwire currents is returned via the active noise
suppression leadwire:
• 0.08 uA DC in 3 lead mode
• 0.16 uA DC in 5 lead mode
Pacemaker option
Type VVI demand; asynchronous (fixed rate) when used without ECG leads
or in asynchronous (Async) pacing mode
Pulse type Rectilinear, constant current
Pulse duration 40 ms ±2 ms
Pulse amplitude (output) Variable 0 mA to 140 mA ±5% or 5 mA, whichever is greater
Increments/decrements by a value of 2 mA
Pacing rate 30 to 180 pulses per minute (ppm) ±1.5%
Increments/decrements by a value of 2 ppm
Output protection Fully defibrillator-protected and isolated
Recorder and Stripchart Printer
Paper 80 mm thermal (grid width)
90 mm (paper width)
Speed 25 mm/s
Delay 6 seconds
Annotations Time, date, defibrillation energy, heart rate, pacer output, QRS
synchronization marker, ECG size, ECG lead, alarm, defibrillator test
result, analyze ECG, diagnostic bandwidth
Messages: ANALYSIS HALTED, NOISY ECG, SHOCK ADVISED,
NO SHOCK ADV.
