A PPENDIX A S PECIFICATIONS
A–4 www.zoll.com 9650-0912-01 Rev. K
Automatic Defibrillator
Test Verifies defibrillator charging and discharging without removing
paddles from storage wells or with OneStep cable connected to the
Test Port or OneStep electrodes.
Defibrillation advisory Evaluates electrode connection and patient ECG to determine if
defibrillation is required.
Shockable rhythms:
• Ventricular fibrillation (VF) with amplitude > 100
V
• Wide-complex ventricular tachycardia (VT) with rates greater than
150 beats per minute (adult), or 200 beats per minute (pediatric).
Refer to “ECG Rhythm Analysis Algorithm Accuracy” on page A-29 for
sensitivity and specificity performance.
CPR Monitoring
Compression depth 0.75 to 3 inches ±0.25 inches
1.9 to 7.6 cm ±0.6 cm
Compression rate 50 to 150 compressions per minute
ECG Monitoring
Patient connection 3-lead cable, 5-lead cable, paddles, or hands-free therapy electrodes
Input protection Fully defibrillator-proof. Special circuitry prevents distortion of ECG
during pacer pulse.
Implanted pacemaker
spike display Dedicated circuitry detects most implanted pacemaker spikes and
provides standard display marker of spike on ECG trace.
Implanted Pulses
Detected ±2 mV to ±700mV amplitude, 0.1ms to 2ms width, with a recharge
constant of 0 to 100ms.
Note: The pacemaker pulse rejection capability for the R Series with
pacemaker pulses alone includes pulses between +/-2mV and
+/-700mV amplitude, with widths between 0.1ms and 2ms and
overshoot from 0 to 100ms.
The pacemaker pulse rejection capability for the R Series with
pacemaker pulses and a normally paced QRS and T wave
includes pulses between +/-2mV and +/-700mV amplitude,
with widths between 0.1ms and 2ms and overshoot from 0 to
100ms.
The pacemaker pulse rejection capability for the R Series with
pacemaker pulses with an ineffectively paced QRS pattern
includes pulses between +/-2mV and +/-700mV amplitude,
with widths between 0.1ms and 2ms and overshoot from 0 to
100ms.
The R Series is not capable of rejecting A-V Sequential
pacemaker pulses.
Bandwidth 0.5 Hz to 21 Hz standard; 0.05 Hz to 150 Hz diagnostic
0.5 Hz to 40 Hz, and 1 Hz to 21 Hz as configurable options
Lead selection I, II, III, aVR, aVL, aVF, V, PADS, PADDLES, INTL PADDLES
P1, P2, P3 with OneStep Pacing electrodes
ECG size 0.5, 1, 1.5, 2, or 3 cm/mV
Current value shown on display.
Heart rate range 0 to 300 beats per minute
