Specifications
A-6 www.zoll.com 9650-0803-01 Rev. B
CO
2
Range: 0 to 150 mmHg
Accuracy CO
2
:
* At sea level.
** Accuracy applies for breath rates of up to 80 bpm. For breath rates above 80 bpm,
accuracy is 4 mmHg or ±12% of reading whichever is greater, for EtCO2 values exceeding
18 mmHg. This is tested according to and is compliant with ISO 21647. To achieve the
specified accuracies for breath rates above 60 breaths/minute, the Microstream FilterLine
H Set for Infant/Neonatal must be used. Above 40 C, ± 1mmHg or ± 2.5% (whichever is
greater) has to be added to the tolerance of the accuracy specs.
Drift of Measurement Accuracy: Over any 24-hour period, the accuracy claims listed above
are maintained.
The accuracy specification is maintained to within 4% for the following gas mixtures (all
values are in Vol.%).
Respiration Range: 0 to 150 breaths per minute
Respiration Rate Accuracy:
0 to 70 bpm: ±1 bpm
71 to 120 bpm: ±2 bpm
121 to 150 bpm: ±3 bpm
Flow rate: 50 ml/min -7.5 + 15 ml/min, flow measured by volume.
CO2 Partial Pressure* Accuracy **
0-38 mmHg ± 2 mmHg
39-99 mmHg ± (5% of reading + 0.08% for every 1 mmHg above 38 mmHg)
100-150 mmHg ± (5% of reading + 0.08% for every 1 mmHg above 38 mmHg)
CO
2
N
2
O
2
N
2
O H
2
0 Anesthetic Agents
1.0 to 13 0 to 97.5 0 to 100 0 to 80 Dry to saturated According to EN 21647
