Propaq M Product Functions
9650-0803-01 Rev. B Propaq M Operator’s Guide 1-7
Respiration Monitoring
The Propaq M is intended for use to continuously monitor respiration rate and to alarm if the
rate falls outside of the range set by the operator. Because the measurement method actually
measures respiratory effort, apnea episodes with continued respiratory effort (such as
obstructive apnea) may not be detected. It is not intended to be used as an apnea monitor. The
patient population will range from newborn (neonate) to adult.
CO
2
Monitoring
The Propaq M is intended for use to make continuous noninvasive measurement and
monitoring of carbon dioxide concentration of the expired and inspired breath and breath rate.
The patient population will range from newborn (neonate) to adult.
Invasive Pressure Monitoring
The Propaq M is intended for use to display and make continuous invasive pressure
measurements from any compatible pressure transducer. The primary intended uses are arterial
blood pressure, central venous pressure and intracranial pressure monitoring. Any contra-
indications of the particular transducer selected by the user shall apply. The patient population
will range from newborn (neonate) to adult.
Propaq M Product Functions
ECG Monitoring
The patient’s ECG is monitored by connecting the patient to the unit via a 3-, 5-, or 12-lead
patient cable. The ECG waveform is presented on the display along with the following
information:
• averaged heart rate, derived by measuring R to R intervals
• lead selection - I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6 (with ECG cable)
• ECG size - 0.125, 0.25, 0.50, 1.0, 2.0, 4.0 cm/mV, AUTO
• status messages
The ECG bandwidth is user selectable.
