Specifications
A-2 www.zoll.com 9650-0803-01 Rev. B
Monitor/Display
Input: 3-lead, 5-lead, or 12-lead patient cable.
Type: Color LCD, 640 x 480 pixels, 800 MCD
Sweep Speed: 25 mm / sec or 50 mm / sec (User Selectable)
Lead Selections: I, II, III, AVR, AVL, AVF, V1-6.
Frequency Response: (User-selectable)
0.67 to 20 Hz Limited mode
0.67 to 40 Hz Monitor Mode
0.25 to 40 Hz Filtered Diagnostic Mode
0.05 to 150 Hz Diagnostic mode
Per methods a, b, and c of EC11 3.2.7.2.
Common Mode Rejection:
Complies with AAMI EC13-2002 section 4.2.9.10.
Tall T-Wave Rejection:
Meets AAMI EC13-2002, section 4.1.2.1c for 0.9 mV
T-wave (0.8 mV with diagnostic response) and 1mV QRS.
Diagnostic Signals Applied to Patient Connections:
Leads off / active noise suppression sensing circuit is < 0.1 microamps DC. The impedance
/respiration detector signal frequency is 72 ± 7 kHz at 77 microamps RMS
pseudo-sinewave into 100 ohms.
Heart Rate Meter: 30 to 300 BPM.
Displayed Heart Rate: Average of last 5 beat-to-beat intervals.
Heart Rate Alarms: User-selectable.
Size: 0.125, 0.25, 0.5, 1, 2, 4 cm/mv and auto-ranging.
Heart Rate Meter Response Time:
Responds to a 40 BPM step increase in heart rate within 4.5 seconds per
AAMI EC-13-2002, section 4.1.2.1.f. Responds to a 40 BPM step decrease within
3.9 seconds per AAMI EC-13-2002, section 4.1.2.1.f. Response times include a
1.0-second display update interval.
Heart Rate Response to Irregular Rhythm: (AAMI EC13-2002, section 4.1.2.1.e.)
Ventricular Bigeminy: 80 BPM (expected)
Slow Alternating Ventricular Bigeminy: 60 BPM (expected)
Rapid Alternating Ventricular Bigeminy: 120 BPM (expected)
Bidirectional Systole: 45 BPM (expected)
