Setting Upper and Lower Systolic Alarm Limits
Initially, the SpO2 Alarm Settings menu specifies whether the SpO2 alarms are enabled (
ON
)
or
disabled (
OFF
),
and displays the default upper and lower systolic limits. The upper and lower
limits can be
ON
or
OFF
(default is
OFF
).The following table lists the default SpO
2
limits for
adult, pediatric, and neonate patients, and gives the range in which you can set these limits:
Using the SpO
2
Parameter Control Panel
Use the navigation keys to highlight and select the SpO
2
numeric display to display the
SpO
2
Parameter Control Panel, on which you can select options that optimize the use of
SpO
2
for the patient:
Figure 9-4 SPO
2
Parameter Control Menu
Patient Type
SpO
2
Limit Default
SpO
2
Limit Range
Adult
Lower: 85%
Upper: 100%
Lower: 50 - 98%
Upper: 52 - 100%
Pediatric
Lower: 85%
Upper: 100%
Lower: 50 - 98%
Upper: 52 - 100%
Neonate
Lower: 85%
Upper: 95%
Lower: 50 - 98%
Upper: 52 - 100%
0 to 30 mmHg
0 to 150 mmHg
CO2 Scale
0 to 100 mmHg
0 to 60 mmHg
SpO2
Lower
Upper
SpO2 Alarm
85
100
Response
Normal
HR/PR Tone
Low
